Wendell Hostetler's Plans announce the release of their
2018 Design, a Super Chipmunk N1114V.

The plans come on two 42" x 108" detailed sheets.
($58.50 plus postage)
All accessories are available.



Specification for the Chipmunk are;
Scale: 30%, Span: 112.8", Length: 91.5"
Wing area:2156 sq. in. Power: 80-120cc's, Weight: 30-32 lbs.

SuperChipmunk30_pct
30% Super Chipmunk
Built by Frank Fels
Painted by Eric Granger


Specification for the Chipmunk are;
Scale: 40%, Span: 150.4", Length: 122"
Wing area: 3128.3 sq. in. Power: 170-220 cc's, Weight: 55-65 lbs.

SuperChipmunk_30pct_02
40% Super Chipmunk
Built and Painted by Eric Granger

Videos
Vans RV 14-A
RV-4
20% Beaver
Wendell Landing Cessna L-19 Bird Dog
Piper Tri-Pacer
Lancair IV
Extra 300 XS
Howard DGA-6 Mr. Mulligan


A Bit of History - Some pictures from earlier years

Sample Plan Sheet - from the Turner Special




Available Plans
- Click on the name to see a finished model or choose "Add to Cart" to purchase.

All Plans $53.50 (Except as noted) plus postage.

New 2018
WACO_YMF-5
Super Chipmunk N1114V 40% $95.00 plus postage
Scale: 40%, Span: 150.4", Length: 122", Weight: 55-65 lb., Wing Area: 3128.3 sq. in., Power: 170-220 cc's.

New 2018
WACO_YMF-5
Super Chipmunk N1114V 30% $58.50 plus postage
Scale: 30%, Span: 112.8", Length: 91.5", Weight: 30-32 lb., Wing Area: 2156 sq. in., Power: 80-120 cc's.

WACO_YMF-5 WACO YMF-5
Scale: 25%, Span: 90", Length: 69.75", Weight: 28-30 lb., Wing Area: 2101 sq. in., Power: 62-80 cc's.
RV 14 Van's RV 14 (tail dragger) and RV 14-A
Scale: 35%, Span: 113.4", Length: 88.55", Wing Area 2236 sq. in., Weight: 32-36 lb., Power 100-120 cc's  Click here for RV 14-A Construction photos.
Beaver20pct 20% DeHavilland DHC-2 Beaver
Scale 20%, Span: 115.2", Length: 72.6", Wing area 1449 sq. in., Weight: 18-24 lbs., Power: 40-60 cc's.

DeHavillandBeaver_22pct

22% DeHavilland DHC-2 Beaver
Scale 22%, Span: 126.72", Length, 79.86", Wing area 1814 sq. in., Weight: 22 to 32 lbs. (wheels/floats), Power: 62 to 75 cc's.
A_36_Bonanza
A-36 Beech Bonanza
Scale: 27%, Wing Span: 108.54", Wing Area: 1849 sq. in, Length: 89.1", Weight 30-32 lbs. Power: 38 to 100 cc's.
RV4
RV-4 Scale 35%
Scale: 35%, Wing Span: 96.6", Wing Area: 1940 sq. in., Length: 85.4", Weight, 23-25 lbs., Power: 33 to 100 cc's.

Piper_PA_28 Piper PA-28 Cherokee
Scale: 30%, Span: 108", Length: 83.88",  Wing Area: 2052 sq. in. Weight: 22 to 26 lbs. Power: 38 to 62 cc's.

Aeronica Champion

Aeronca Champion:
Scale: 26% Span: 109" Length: 67" Weight: 12 to 15 lbs. Area: 1622 sq. in. Power: Electric, gas or glo.

Jeep

Art Chester's Jeep:
Scale: 42.5% Span: 84" Length: 75.5" Power: 3 to 4.6 cu. in.




Bucker Jungmeister:
Scale: 29% Span: 77" Length: 69" Power: 3 to 6 cu. in.


Cessna 150/152:
Scale: 30% Span: 120" Length: 86.7" Power: 2.5 to 4 cu in.

 Cessna 170:
Scale: 27%, Span: 118.84", Length: 81", Wing Area: 1800 sq. in., Weight: 20 to 22 lbs., Power: 38 to 62 cc's.

Cessna172


Cessna 172 Skyhawk:
Scale: 28% Span: 120" Length: 90" Power: 3 to 4 cu. in.
Cesna182
Cessna 182:
Scale: 26% Span: 120" Length: 82" Area: 2080 sq. in. Engine: 3-4 cu. in. Weight: 26-29 lbs.

Cessna185
Cessna 185:
Scale: 26% Span: 120" Length: 84" Area: 2080 sq. in. Engine: 4-6 cu. in. Weight: 24-28 lbs.

CessnaSkymaster
Cessna Skymaster:
Scale: 26% Span: 119" Length: 92.8"  Power: 1.8 minimum each engine. (will accommodate many types of engines)

Cessna195

Cessna 195
Scale: 25% Span: 108.5", Weight: 16 to 18 lbs., Length 82", Wing Area: 1824 sq. in. Power: 1.7 to 3 cu. in. or Electric (1600 to 2400 watts)

Cessna206

Cessna 206 Stationair:
Scale: 26% Span: 120" Length: 82" Power: 3 to 5

Cessna310R

Cessna 310R:  $58.50 plus postage
Scale: 26% Span: 115" Length: 99.7" Area: 1826 sq. in. Weight: 32-35 lbs. Power: 1.8 to 3 cu. in. per engine

Cessna421C

Cessna 421C  $58.50 plus postage
Scale: 24% Span: 118" Length: 104.77" Power: 3.6 to 8 (Both Engines)

Cessna421C

Cessna 421C  $70.50 plus postage
Scale: 27% Span: 133.25" Length: 117.87" Power: 4 to 8 (Both Engines)

CessnaL19Birddog

 Cessna L-19 Bird Dog
Span: 116.64", Length: 81", Wing area: 1800 sq. in., Weight: 20 to 22 lbs., Scale: 27%, Power: 38 to 62 cc's.

HowardDGA6

Howard DGA-6 (Mr. Mulligan)
Span: 98.8", Length: 78.26", Wing area: 1544 sq. in., Weight: 22 to 26 lbs., Scale: 26%, Power: 45 to 75 cc's.

J3_cub

J-3 Cub/Super/Clipped Wing Cub:
Scale: 30% Span: 127" Length: 79"   Power: 2 to 4


Floats

J-3 Float Plans:
60" Amphibious floats on our 30% J3 Cub. (Retracts are available).  Floats fit planes from 120" to 130" span. (25 to 35 lbs.)

CurtisHawk

Curtis Hawk P6E:
Scale: 22% Span: 84" Length: 63.5" Power: 3 to 4.6.

SuperDecathalon_30pct

Super Decathlon:
Scale 30% Span 115" Area: 2240 sq. in Weight: 22-24 lbs. Length: 81.8" Power: 3-6 cu. in.

SuperDecathlon

Super Decathlon: $58.50 plus postage
Scale 33% Span 126.72" Area: 2626 sq. in Weight: 25-30 lbs. Length: 89.6" Power: 6-7 cu. in.

Diabolo

Diabolo:
Scale: 35% Span: 97" Length: 75" Power: 4 to 6.

Edge540T

Edge 540T:
Scale: 34% Span: 103" Area: 1687 sq. in Weight: 24-26 lbs. Length: 89.75" Power: 3.2 to 6.

Extra300XS_27pct

27% Extra 300XS:
Scale 27% Span: 80" Area: 1185 sq. in Weight: 12.5 lbs. Length: 71.7"
Power: Hacker brushless C50-14XL6.7 with 2 - 8000 mah 4S4P Li-Poly in series, 22/14 prop
For non-electric, Moki 2.10 or equal.

Extra300XS_33pct

33% Extra 300 XS:  $58.50 plus postage
Scale 33% Span: 97.4", Length: 86.37", Wing area: 1762 sq. in., Weight: 24-26 lbs.,
Power: 100 cc (6 ).

Extra300XS_40pct

40% Extra 300 XS $72.50 plus postage
Scale 40% Span: 118", Wing area: 2525 sq. in., Power: 150 cc (9 ),
Length: 104.6", Weight: 35 - 39 lbs. approx.

Fairchild24

Fairchild 24 R &/or W:
Span: 117", Length: 76.95", Wing area: 1941 sq. in., Weight: 20 to 22 lbs., Scale: 27%, Power: 3 to 4 cu. in.

FairchildPT19

Fairchild PT-19:
Scale: 26% Span:114" Length: 85" Power: 2.4 to 4.

FullTiltBoogie

Full Tilt Boogie:
Scale: 35% Span: 61.5" Length: 63" Power: 2 to 4.6.

GeeBee25pct

Gee Bee R2:
Scale: 25% Span: 80" Length: 56.5" Power: 3 to 4.6.

GeeBee33pct

33% Gee Bee R2: $56.50 plus postage
Scale: 33% Span: 100" Length: 70.9" Power: 6 to 8.8.

GeeBeeZ29pct

Gee Bee Z:
Scale: 29% - Span: 81" Length: 52.5" Area: 1083 sq. in. Engine: 2-3.7 cu. in. Weight: 19-23 lbs.

GeeBeeZ33pct

Gee Bee Z: $56.50 plus postage
Scale: 33% - Span: 93" Length: 59.73" Area: 1430 sq. in. Engine: 4-6 cu. in. Weight: 26-28 lbs.

GeeBeeZ_40pct

Gee Bee Z: $72.50 plus postage
Scale: 40% - Span: 112" Length: 72.5" Area: 2000 sq. in. Engine: 6-8 cu. in. Weight: 35-40 lbs.

Giles202_35pct

Giles 202:
Scale: 35% Span: 92.4" Length: 82.95" Power: 4 to 6.

Giles202_42pct

Giles 202: $65.50 plus postage
Scale: 42% Span: 110.8" Length: 99.5" Power: 7 to 8.

Giles202_55pct

Giles 202:  $69.50 plus postage
Scale: 55% Span: 144" Length: 128" Weight: 60 lbs. Wing Area: 4010 sq. in. Power: 240 cc (14.6 ).

LancairIV

Lancair IV:
Scale: 27.6% Span: 100" Length: 82.8" Power: 3 & up.

LancairES

Lancair ES:
Scale: 27.6% Span: 118" Length: 82.8" Power: 3 to 6
ES is fixed gear version and is included in the same plan set as the Lancair IV.

LiberySport

Liberty Sport:
Scale: 24% Span: 77" Length: 64.6" Power: 2 to 4.

LockheedSirius

Lockheed Sirius:
Scale: 20% Span: 102.8" Length: 66" Power: 2 to 4.

LuscombeSilvair8

Luscombe Silvair 8:
Span 121.8", Length: 69.6", Wing area: 1703 sq. in., Weight 17 to 19 lbs. Power 2 to 3 , Scale: 29%.

L17Navion

L-17 Navion:
Span: 108.15", Weight: 28 to 32 lbs., Length: 88.29", Wing Area: 1855 sq. in., Power 3 to 4 cu. In.

Nemesis

Nemesis:
Scale: 42% Span: 105.8" Length: 90.7" Power: 3 to 6.

Pawnee

Pawnee:
Span: 119.35", Weight: 24 to 26 lbs., Length: 81.7", Wing Area: 1934.5", Power: 3 to 6.

PiperPA15Vagabond

Piper PA-15 Vagabond:
Scale: 32.5% Span: 114" Length: 73" Power: 2.5 to 4.

PiperTriPacer

Piper Tri-Pacer:
Scale: 33% Span: 115" Length: 81.6" Power: 2.4 to 4.0 cu. in.

PittxS1_11B_35pct

Pitts S-1-11B:
Scale: 35% Span: 75" Length: 76.3" Power: 4 to 6

PittsS1_11B_45pct

Pitts S-1-11B:  $69.50 plus postage
Scale: 45% Span: 97.2" Length: 98.1" Power: 8.8 to 10 cu. in.

Skybolt

Skybolt:
Scale: 26.5% Span: 76.5" Length: 66.5" Power: 3 to 6.

StinsonReliantSR10

Stinson Reliant SR-10:
Scale: 25% Span: 125.6" Length: 82.86" Power: 3 to 5.

StinsonVoyger108

Stinson Voyager 108:
Scale: 26.6% Span: 108" Length: 80.33" Area: 1557.8 sq. in. Weight: 14-15 lbs.
Power: Hacker C50-14XL-6.7:1, 8000 mah 2-4S4P Li-Poly Batteries
Glo/Gas option (without modification to plans) Moki 2.10 or equal.

TaylorcraftBC12D

Taylorcraft BC-12-D:
Scale: 26% Span: 112" Length: 68.84" Power: Electric: 1200-2000 watts Gas/glo: 1.2 to 2.6.

TurnerSpecial

Turner Special:
Scale: 25% Span: 84" Length: 70" Power: 3 to 4.6.

WendellWilliamsGilmore

Wedell-Williams Gilmore "Red Lion":
Scale" 25% Span: 84" Length: 67" Power: 3 to 4.6.

54" Floats - $25.50 plus postage

60" Floats (retracts optional) - $25.50 plus postage


50" Float plans for the 20% DeHavilland DHC-2 Beaver - $25.50 plus postage


All of our designs may be purchased in any size. They are plotted on a laser printer with black lines on a high quality white paper. Due to the custom plotting process, the cost is higher than our regular plan prices. No fiberglass parts, formed windshields, or gear are available for special sizes.

Order Form

NOTE ON POSTAGE:
$10.00 U.S.A East of the Mississippi,
$13.00 U.S.A West of the Mississippi, ,
$15.50 Canada.
All orders outside the continental U.S.A. $23.50.
